Contact Type 220V Variac Voltage Regulator Single Phase Variac Variable Transformer

Name: Contact Type 220V Variac Voltage Regulator Single Phase Variac Variable Transformer
Brand: YOMIN
Price: 28.6 USD

Wholesale Contact Type 220V Variac Voltage Regulator Single Phase Variac Variable Transformer from china suppliers

Brand Name : YOMIN

Model Number : TDGC2-0.5

Certification : ROSH

Place of Origin : China (Mainland

MOQ : 1 piece

Price : USD 28.6-41.34/piece

Payment Terms : L/C, T/T, Western Union, D/A, D/P

Supply Ability : 170000 PCS/Month

Delivery Time : Within one week after payment.

Packaging Details : Within one week after payment.

Current Type : AC

Phase : Single phase

Product Name : Variac Voltage Regulator

Output : 0~250V AC

Usage : voltage regulator

Capacity/Power : 1500VA-60KVA

Color : Pale yellow

MOQ : 1 Piece

Packing : Standard export packing

Voltage change rate : ±1%

Temperature rise : ≤60°C

Insulation resistance : ≥150MΩ

Electric strength : 2000VAC/1min

Contact Now

Single Phase Variac Variable Transformer 220V Manufacturer variable transformer

Product description

TDGC2 Series Contact Type Voltage Regulator belongs to the Adjustable Variac/Autotransformer structure. The coil wound evenly on the toroidal core, the carbon brush holder installed in the spindle, under the pressure of spring, the carbon brush contacts the coil surface closely. Adjusting the spindle to drive the carbon brush holder to make the carbon brush move on the coil surface and change the carbon brush contact position, that is to say, changing the variac primary and secondary winding/turns ratio, which make the output voltage smoothly adjust with the adjustable range.

Technical parameters

Capacity/Power	500VA-30KVA (Other power can be customized)
Input Voltage	220VAC (Other voltage can be customized)
Output Voltage	0-250VAC (Other range can be customized)
Max. Output Current	Power in KVA*1000/Max. Output Voltage
Working Frequency	50Hz/60Hz±5%
Efficiency	≥98%
Waveform Distortion	Nil
Ambient Temperature	-15°C to +45°C
Altitude	≤1000m
Relative Humidity	≤95%
Insulation Class	A
Temperature Rise	<60℃
Dielectric Strength	No damage at 2000V for 1 minute
Insulation Resistance	≥5MΩ
Display	Analogue Meter (Optional: LED or LCD Screen)
Installation	Indoor and floor mounted
Protection Degree (IP Rating)	IP20
Cooling	Dry type air cooled

Contact Type 220V Variac Voltage Regulator Single Phase Variac Variable Transformer

Product packaging

Contact Type 220V Variac Voltage Regulator Single Phase Variac Variable Transformer
